HM100180 Handheld Metal Detector
The HM100180 is a lightweight handheld metal detector designed for security screening and inspection checks. It features adjustable sensitivity, audible and vibration alarm modes, a high-brightness LED indicator and a rugged body designed to withstand accidental drops from up to 2 metres under specified conditions.
Key Features of HM100180
The HM100180 supports handheld security inspections with adjustable sensitivity, multiple alarm options and a portable design for convenient everyday use.
Handheld Portable Design
The lightweight handheld form makes it convenient for security personnel to carry and use during inspection checks.
Adjustable Sensitivity
Sensitivity can be adjusted to suit different screening requirements and the types of metal objects being checked for.
Audible and Vibration Alarms
Two alarm modes provide sound or vibration alerts to suit different inspection environments and operator preferences.
One-Touch Sensitivity Adjustment
The one-touch sensitivity adjustment function is designed to make operation simple and convenient for security staff.
Rugged Construction
The product specifications describe a rugged body designed to withstand a free-fall drop from a height of up to 2 metres under specified conditions.
Battery Powered
Operates with a standard 9V 6F22/15F8H battery or a compatible rechargeable battery for portable inspections.
Technical Specifications of HM100180
Important product dimensions, power details, operating conditions and detection ranges for the HM100180 handheld metal detector.
| Specification | Details |
|---|---|
| Model | HM100180 |
| Product Type | Handheld Metal Detector |
| Product Dimensions | 415 × 85 × 45 mm |
| Net Weight | 400 g |
| Working Frequency | 0–25 kHz |
| Package Dimensions | 520 × 100 × 50 mm |
| Power Supply | Standard 6F22/15F8H 9V battery or compatible rechargeable battery |
| Operating Temperature | -15°C to +55°C |
| Alarm Modes | Audible and vibration |
| Visual Indicator | High-brightness LED indicator |
| Sensitivity | Adjustable; one-touch adjustment function |
| Drop Resistance | Designed to withstand a free-fall drop from up to 2 metres under specified conditions |
| Detection Range — Pin | 25–70 mm |
| Detection Range — Type 64 Pistol | 0–350 mm |
| Detection Range — Six-Inch Dagger | 200–300 mm |
| Detection Range — 20 mm Steel Ball | 150 mm |
| Detection Range — ₹1 Coin | 120–180 mm |
| Detection Range — TF Card, Staples and 8-Pin Chip | 10–40 mm |
| Charging | Rechargeable battery can be charged using a compatible original charger |
