FHT-TL-149 Full Height Turnstile – Single Door
The FHT-TL-149 Full Height Turnstile is designed to control pedestrian entry and exit at secured premises, industrial facilities and restricted-access areas. Its full-height single-door structure and three-arm rotor create a defined passage to help deter unauthorized entry.
Built with a corrosion-protected stainless steel frame, the FHT-TL-149 features a DC electromagnetic drive, adjustable hydraulic damper and configurable one-way or bi-directional operation. RS485 or TCP/IP communication options support integration with compatible access control equipment.
FHT-TL-149 Full Height Turnstile Features
Explore the construction, access-control integration and operating features of the FHT-TL-149.
Corrosion-Protected Stainless Steel
The frame is made from stainless steel with corrosion protection for demanding access-control installations.
Full Height Single-Door Design
The full-height rotor and shield assembly create a defined pedestrian passage to help prevent unauthorized bypassing.
Three-Arm Rotor
The turnstile uses a three-arm configuration with a 120-degree section design to manage pedestrian passage.
RS485 or TCP/IP Communication
Communication options support integration with compatible access control systems and connected equipment.
Adjustable Hydraulic Damper
The adjustable hydraulic damper helps control the rotor's movement during operation.
Flexible Passage Modes
Supports single passage in a set direction, bi-directional passage, free passage and always-free or locked operating modes.
FHT-TL-149 Technical Specifications
Review the published dimensions, electrical requirements and operating specifications.
| Product Model | FHT-TL-149 |
|---|---|
| Product Type | Full Height Turnstile – Single Door |
| Dimensions (L × W × H) | 1630 × 1500 × 2310 mm |
| Net Weight | 220 kg |
| Passage Width | Less than 650 mm |
| Frame Material | Stainless steel with corrosion protection |
| Number of Arms | 3 |
| Section Version | 120 degrees |
| Drive Type | DC electromagnetic drive |
| Power Supply | 100–240V AC |
| Control Circuit | 24V DC |
| Power Consumption | 30W |
| Frequency | Less than 50Hz or 60Hz, as listed by the manufacturer |
| Hydraulic Damper | Adjustable |
| Solenoid | 24V DC, 100% |
| Communication Interface | RS485 or TCP/IP |
| Operating Temperature | -25°C to +70°C |
| Humidity | Up to 95%, as listed by the manufacturer |
| Protection Level | Greater than 44, as listed by the manufacturer |
| Mean Cycles Between Failures (MCBF) | 5 million cycles |
| Closing Delay | Adjustable from 1 to 60 seconds after a valid card reading |
| Traffic Modes | Single passage in set direction, bi-directional single passage, free passage, always free or locked |
| Reader Locations | 4 |
| Optional Equipment | IC/ID card reader, barcode reader, other compatible read/write equipment, UPS and infrared detector |
| Frame Protection | Waterproof seal |
Frequently Asked Questions
Common questions about the FHT-TL-149 Full Height Turnstile.
What is the FHT-TL-149 Full Height Turnstile?
The FHT-TL-149 is a single-door full height turnstile designed to control pedestrian entry and exit at restricted-access facilities.
What are the dimensions of the FHT-TL-149?
The manufacturer's product page lists dimensions of 1630 × 1500 × 2310 mm and a net weight of 220 kg.
How many arms does the FHT-TL-149 have?
The manufacturer's product page lists three arms and a 120-degree section version.
Which communication interfaces are available?
The listed communication interfaces are RS485 or TCP/IP, allowing connection to compatible access control equipment.
Can the turnstile operate in both directions?
Yes. Listed operating modes include single passage in a set direction and bi-directional single passage. Free-passage and always-free or locked modes are also specified.
Does the FHT-TL-149 support card readers?
Optional equipment includes IC/ID card readers, barcode readers and other compatible read/write devices. The final configuration depends on the connected access control system.
What are its electrical requirements?
The manufacturer lists a 100–240V AC power supply, 24V DC control circuit and 30W power consumption.
How can I enquire about the FHT-TL-149?
Contact CDN Technologies through the website enquiry page or WhatsApp to ask about pricing, availability, reader integration and installation requirements.
